Keys
Ignition Key
This motorcycle has two ignition keys and a key
tag with a key number and a bar code.
The ignition key contains a special coded chip that
is recognized by the immobilizer system (HISS) in
order to start the engine. Handle the key carefully
to prevent damaging the HISS components.
● Do not bend keys or subject them to undue
stress.
● Avoid prolonged exposure to sunlight or high
temperatures.
● Do not grind, drill or in any way alter their
shape.
● Do not expose to strong magnetic objects.
If you lose all ignition keys and the key tag, the
PGM-FI unit/ignition control module must be
replaced by your dealer. To avoid this, keep a
duplicate key.
If you lose a key, make another duplicate key
immediately.
To make a duplicate key and register it with your
HISS system, take the spare key, the key tag, and
the motorcycle to your dealer.
u Store the key tag in a safe location.
A metal key holder may cause damage to the area
surrounding the ignition switch.
20171109154101_32MKK8000_eng_BOOK Page 181 Thursday, November 09 2017 15:56:56 JST
Keys
Information
176
Ignition key Key tag
Key number and bar code

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
