When removing and installing the wheel, be
careful not to damage the wheel speed
sensor and pulser ring.
#
Front Wheel
Removal
1. Place your motorcycle on a firm, level
surface.
2.
Cover both sides of the front wheel and
brake caliper with protective tape or cloth.
3.
On the right side, remove the mounting
bolts and remove the brake caliper.
4.
On the left side, remove the mounting
bolts and remove the brake caliper.
u Support the brake caliper assembly so
that it doesn’t hang from the brake
hose. Do not twist the brake hose.
u Avoid getting grease, oil, or dirt on the
disc or pad surfaces.
u
Do not pull the brake lever while the
brake caliper is removed.
u
Take care to prevent the brake caliper
from scratching the wheel during
removal.
20171109154101_32MKK8000_eng_BOOK Page 164 Thursday, November 09 2017 15:56:56 JST
Tyre Puncture u Removing Wheels
Troubleshooting
159
Continued
Mounting bolts
Brake caliper Tape or cloth

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
