Honda Africa Twin CRF1000 2017 User Manual

Parking Brake
CRF1000D/D II
Parking Brake Lever
Be sure the parking brake is applied while
parking and warming up the engine.
u Make sure the parking brake lever is
released before riding.
To apply the parking brake
Squeeze the parking brake lever (a) fully
then rotate the lock lever (b) clockwise until
it engages the slot on the parking brake lever
bracket back to lock the rear wheel.
u
The parking brake lock will not function if
the parking brake is not adjusted properly.
(P.128
)
To release the parking brake
Squeeze the parking brake lever until the
lock lever is released from the slot on the
parking brake lever bracket.
u
Before riding, check that the parking brake
indicator is turned off and make sure that
the parking brake is fully released so there is
no drag on the rear wheel.
20171109154101_32MKK8000_eng_BOOK Page 66 Thursday, November 09 2017 15:56:56 JST
Operation Guide
61
Lock lever
Parking brake lever
Slot

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
