Honda Africa Twin CRF1000 2017 User Manual

Specifications
■ Main Components
Overall length
CRF1000A/D
2,330 mm (91.7 in)
CRF1000A II/D II
2,340 mm (92.1 in)
Overall width 930 mm (34.4 in)
Overall height
CRF1000A/D
1,475 mm (58.1 in)
CRF1000A II/D II
1,570 mm (61.8 in)
Wheelbase
CRF1000A/D
1,575 mm (62.0 in)
CRF1000A II/D II
1,580 mm (62.2 in)
Minimum ground clearance
CRF1000A/D
250 mm (9.8 in)
CRF1000A II/D II
270 mm (10.6 in)
Caster angle 27° 30’
Trail
CRF1000A/D
113 mm (4.4 in)
CRF1000A II/D II
111 mm (4.4 in)
Curb weight
CRF1000A
ED, II ED, III ED, II
KO, III KO type
230 kg (507 lb)
U, II U, III U type
229 kg (505 lb)
CRF1000D
ED, II ED, III ED, II
KO, III KO type
240 kg (529 lb)
U, II U, III U type
239 kg (527 lb)
CRF1000A II
IV ED type
243 kg (536 lb)
IV U type
242 kg (534 lb)
CRF1000D II
IV ED type
253 kg (558 lb)
IV U type
252 kg (556 lb)
IV KO type
255 kg (562 lb)
20171109154101_32MKK8000_eng_BOOK Page 194 Thursday, November 09 2017 15:56:56 JST
Specifications
189

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
