Honda Africa Twin CRF1000 2017 User Manual

Removing & Installing Body Components
Battery
#
Removal
Make sure the ignition switch is in the
(Off) position.
1.
Remove the tool box. 2 P. 117
2.
Disconnect the negative - terminal from
the battery.
3.
Disconnect the positive + terminal from
the battery.
4.
Remove the clip. 2 P. 111
5.
Open the battery box band.
6.
Remove the battery from the battery case
taking care not to drop the terminal nuts.
#
Installation
Install the parts in the reverse order of
removal. Always connect the positive +
terminal first.
Make sure that bolts and nuts are tight.
Make sure the clock information is correct
after the battery is reconnected. 2 P. 44
20171109154101_32MKK8000_eng_BOOK Page 114 Thursday, November 09 2017 15:56:56 JST
Maintenance
109
Continued
Battery box
band
Positive terminal
Negative
terminal
Battery
Bolts
Terminal nuts
Clip

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
