Honda Africa Twin CRF1000 2017 User Manual

Brakes
Checking Brake Fluid
1.
Place your motorcycle in an upright
position on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
is horizontal and that the fluid level is
above the LOWER level mark.
Rear
Check that the brake fluid reservoir
is horizontal and that the fluid level is
between the LOWER level and UPPER
level marks.
If the brake fluid level in either reservoir is
below the LOWER level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear.
If the brake pads are not worn, you most
likely have a leak. Have your motorcycle
inspected by your dealer.
20171109154101_32MKK8000_eng_BOOK Page 131 Thursday, November 09 2017 15:56:56 JST
Maintenance
126
Front brake fluid reservoir
LOWER
level mark
UPPER
level mark
LOWER
level mark
Rear brake fluid reservoir
Front Rear

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
