Honda Africa Twin CRF1000 2017 User Manual

#
License Plate Light Bulb
1.
Remove the screws.
2.
Remove the license plate light cover and
license plate light cover packing.
3.
Pull out the bulb without turning it.
4.
Install a new bulb and parts in the reverse
order of removal.
Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 99
#
Fuse Box Fuses
1.
Remove the front seat. 2 P. 112
2.
Open the fuse box covers.
3.
Pull the fuses out with the fuse puller in
the tool kit one by one check for a blown
fuse. Always replace a blown fuse with a
spare fuse of the same rating.
4.
Close the fuse box covers.
5.
Reinstall the front seat.
20171109154101_32MKK8000_eng_BOOK Page 175 Thursday, November 09 2017 15:56:56 JST
Electrical Trouble u Blown Fuse
Troubleshooting
170
Screws
License plate light
cover
Bulb
Cover packing

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
