Honda BF15D Owner's Manual

22
CONTROLS AND FEATURES
Power tilt is a convenience for
tilting the motor, shallow water
operation, and trailering only. It is
not designed to be used as a trim
function to adjust the trim angle of
the boat.
TILT LEVER
POWER TILT SWITCH
Press UP
to tilt the
motor up.
Press DN to tilt
the motor down.
TTIILLTT
RRUUNN
((LLOOCCKK))
Power Tilt Switch (T type) Tilt Lever (G type)
(gas assist tilt type)
Moving the tilt lever to the TILT
position allows the outboard motor to
be tilted and moving the tilt lever to
the RUN (LOCK) position locks the
outboard motor in the desired
position. Use the tilt lever to
temporarily tilt the outboard motor
when the boat is operating in shallow
water, or mooring in shallow water.
The tilt lever must be in the RUN
(LOCK) position before operating
the outboard motor or the motor
could tilt up when operating in
reverse.
The rocker type power tilt switch has
UP and DN (down) positions for
changing the angle of the outboard
motor.
During shallow water operation,
beaching, launching, or mooring,
proceed at low speed with a small
throttle opening and tilt the motor up
as necessary (p. ).59
04/03/15 10:25:09 31ZY0600_023

Honda BF15D Specifications

General

Displacement	350 cc (21.4 cubic inches)
HP Rating	15 HP
Fuel Delivery	1 Carburetor
Ignition System	Digital CDI
Cooling System	Water Cooled
Gear Ratio	2.08:1
Lubrication	Wet Sump
Gear Shift	F-N-R
Engine Type	4-stroke
Full Throttle RPM Range	5000 - 6000 rpm
Starting System	Manual
Exhaust	Through Propeller
Fuel Tank Capacity	External tank
Oil Capacity	1.1 L
Fuel	Unleaded Gasoline
Shaft Length	15 inches
