Honda BF15D Owner's Manual

82
Portable Fuel Tank and Filter
Cleaning
SERVICING YOUR OUTBOARD MOTOR
ARROW
(Fuel Flow Direction)
TANK FILTER JOINT
(Fuel Hose Connector)
O-RING
FILTER
Fuel Tank
Fuel Tank Filter
Install the new filter on the fuel
hoses, with the fuel flow arrow
pointing toward the fuel pump as
shown. Fuel flow will be impeded
if the filter is installed backward.
Install and lock the engine cover.
Empty the portable fuel tank into an
approved gasoline container. Use a
funnel to avoid spilling fuel. Rinse
the fuel tank with nonflammable
solvent to remove any accumulated
sediment.
Unscrew the fuel hose connector
by turning it counterclockwise,
then remove the fuel hose
connector and fuel filter from the
tank.
Clean the filter in nonflammable
solvent. Inspect the fuel tank filter
and the connector O-ring. Replace
them if damaged.
Reinstall the filter and hose
connector in the fuel tank. Tighten
the hose connector securely.
Remove the fuel hose clamps, and
connect the fuel hose to the
outboard motor. Check for leaks.
5.
6.
7.
1.
2.
3.
04/03/15 10:36:13 31ZY0600_083

Honda BF15D Specifications

General

Displacement	350 cc (21.4 cubic inches)
HP Rating	15 HP
Fuel Delivery	1 Carburetor
Ignition System	Digital CDI
Cooling System	Water Cooled
Gear Ratio	2.08:1
Lubrication	Wet Sump
Gear Shift	F-N-R
Engine Type	4-stroke
Full Throttle RPM Range	5000 - 6000 rpm
Starting System	Manual
Exhaust	Through Propeller
Fuel Tank Capacity	External tank
Oil Capacity	1.1 L
Fuel	Unleaded Gasoline
Shaft Length	15 inches
