Honda BF15D Owner's Manual

44
FUEL PRIMING STARTING THE ENGINE
OPERATION
ENGINE STOP
SWITCH
LANYARD
OUTLET END
(MOTOR)
INLET END
(TANK)
PRIMING BULB
SWITCH CLIP
H Type (tiller handle)
Check to be sure there are no fuel
leaks before starting the engine.
Hold the priming bulb with the outlet
end higher than the inlet end.
Squeeze the priming bulb several
times, until it feels firm, indicating
that fuel has reached the carburetor.
Put the emergency stop switch clip
in the engine stop switch, and
attach the lanyard to your PFD
(Personal Flotation Device) or to
your wrist, as shown.
The emergency stop switch clip
and lanyard system is a safety
device that will stop the engine if
you fall away from the controls
while operating the boat.
Always attach the lanyard to your
PFD, or to your wrist, before
starting the engine.
The engine will not start or run,
unless the switch clip is in the
engine stop switch.
Do not squeeze the priming bulb
when the engine is running because
that could flood the carburetor.
1.
04/03/15 10:29:19 31ZY0600_045

Honda BF15D Specifications

General

Displacement	350 cc (21.4 cubic inches)
HP Rating	15 HP
Fuel Delivery	1 Carburetor
Ignition System	Digital CDI
Cooling System	Water Cooled
Gear Ratio	2.08:1
Lubrication	Wet Sump
Gear Shift	F-N-R
Engine Type	4-stroke
Full Throttle RPM Range	5000 - 6000 rpm
Starting System	Manual
Exhaust	Through Propeller
Fuel Tank Capacity	External tank
Oil Capacity	1.1 L
Fuel	Unleaded Gasoline
Shaft Length	15 inches
