Honda BF15D Owner's Manual

25
CONTROLS AND FEATURES
GEARSHIFT/THROTTLE
CONTROL LEVER
N (neutral)
R (reverse)F(forward)
EENNGGIINNEE
SSPPEEEEDD
EENNGGIINNEE
SSPPEEEEDD
GEARSHIFT/THROTTLE
CONTROL LEVER
NEUTRAL RELEASE LEVER
HIGH
HIGH
Gearshift/Throttle Control
Lever (side-mount type)
The gearshift/throttle control lever
controls engine speed and selects F
(forward), N (neutral), or R (reverse)
gears.
Moving the control lever 30° from N
(neutral) selects the gear, and further
movement increases engine speed.
A friction adjuster near the base of
the control lever adjusts the operating
resistance of the control lever (p. ).
Less friction allows easier control
lever movement. More friction helps
to hold a steady throttle setting while
cruising.
The control lever automatically locks
itself in the N (neutral) position. To
move the lever out of the N (neutral)
position, you must squeeze the
neutral release lever on the underside
of the lever handle.
55
04/03/15 10:25:43 31ZY0600_026

Honda BF15D Specifications

General

Displacement	350 cc (21.4 cubic inches)
HP Rating	15 HP
Fuel Delivery	1 Carburetor
Ignition System	Digital CDI
Cooling System	Water Cooled
Gear Ratio	2.08:1
Lubrication	Wet Sump
Gear Shift	F-N-R
Engine Type	4-stroke
Full Throttle RPM Range	5000 - 6000 rpm
Starting System	Manual
Exhaust	Through Propeller
Fuel Tank Capacity	External tank
Oil Capacity	1.1 L
Fuel	Unleaded Gasoline
Shaft Length	15 inches
