Engine Will Not Start
Starter Motor Operates But
Engine Does Not Start
Check the following items:
● Check the correct engine starting
sequence. 2 P. 45
●
Check that there is petrol in the fuel tank.
● Check if the PGM-FI malfunction indicator
lamp (MIL) is on.
u If the indicator lamp is on, contact
your dealer as soon as possible.
Starter Motor Does Not
Operate
Check the following items:
● Check the correct engine starting
sequence. 2 P. 45
●
Make sure engine stop switch is in the
(Run) position. 2 P. 42
● Check for a blown fuse. 2 P. 116
●
Check for a loose battery connection
(2 P. 69) or battery terminal corrosion
(2 P. 58).
● Check the condition of the battery.
2 P. 113
If the problem continues, have your
motorcycle inspected by your dealer.
20171012170126_32K98B000_eng_BOOK Page 104 Thursday, October 12 2017 17:09:26 JST
Troubleshooting
101
