Clip
#
Removal
1. Press down on the centre pin to release
the lock.
2. Pull the clip out of the hole.
#
Installation
1. Push the bottom of the centre pin.
2. Insert the clip into the hole.
3. Press down on the centre pin to lock the
clip.
20171012170126_32K98B000_eng_BOOK Page 74 Thursday, October 12 2017 17:09:26 JST
Removing & Installing Body Components u Clip
Maintenance
71
Centre pin
a b
a
b c
