Fuel Tank Cover Assembly
#
Removal
1. Remove the front seat. 2 P. 72
2. Remove the left and right inner cover by
removing the clip.
3. Remove the bolt A and bolts B.
20171012170126_32K98B000_eng_BOOK Page 76 Thursday, October 12 2017 17:09:26 JST
Removing & Installing Body Components u Fuel Tank Cover Assembly
Maintenance
73
Continued
Clip
Inner cover
Left side
Bolt B
Bolt B
Bolt B
Bolt A
