Front Seat
#
Removal
1.
Remove the rear seat. 2 P. 78
2.
Remove the mounting bolts and collars,
and then pull the front seat back and up.
#
Installation
1.
Insert the tab into the recess.
2.
Install the collars and mounting bolts.
3.
Tighten the mounting bolts securely.
Torque: 10 N·m (1.0 kgf·m, 7 lbf·ft)
u Make sure that the seat is locked
securely in position by pulling it up
lightly.
4.
Install the rear seat. 2 P. 78
20171012170126_32K98B000_eng_BOOK Page 75 Thursday, October 12 2017 17:09:26 JST
Removing & Installing Body Components u Front Seat
Maintenance
72
Recess
Front seat
Mounting
bolts
Collars
Tab
To Next Page
