■ Bulbs
Headlight LED
Brake/Tail light LED
Front turn signal light LED
Rear turn signal light LED
License plate light LED
■ Fuses
Main fuse 30 A
Other fuse 30 A, 20 A, 10 A, 7.5 A
■ Torque Specifications
Front seat mounting bolt 10 N·m (1.0 kgf·m, 7 lbf·ft)
Fuel tank cover bolt B 4.2 N·m (0.4 kgf·m, 3.1 lbf·ft)
Fuel tank cover bolt A 10 N·m (1.0 kgf·m, 7 lbf·ft)
Fuel tank mounting bolt 12 N·m (1.2 kgf·m, 9 lbf·ft)
Engine oil drain bolt 25 N·m (2.5 kgf·m, 18 lbf·ft)
Rear axle nut 88 N·m (9.0 kgf·m, 65 lbf·ft)
Front axle nut 59 N·m (6.0 kgf·m, 44 lbf·ft)
Front axle pinch bolt 24 N·m (2.4 kgf·m, 18 lbf·ft)
20171012170126_32K98B000_eng_BOOK Page 135 Thursday, October 12 2017 17:09:26 JST
Specifications
Specifications
132
