Brakes
Checking Brake Fluid
1.
Place your motorcycle in an upright
position on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
is horizontal and that the fluid level is
above the LWR mark.
Rear
Check that the brake fluid reservoir
is horizontal and that the fluid level is
between the LOWER level and UPPER
level marks.
If the brake fluid level in either reservoir is
below the LWR mark or LOWER level mark or
the brake lever and pedal freeplay becomes
excessive, inspect the brake pads for wear.
If the brake pads are not worn, you most
likely have a leak. Have your motorcycle
inspected by your dealer.
20171012170126_32K98B000_eng_BOOK Page 89 Thursday, October 12 2017 17:09:26 JST
Maintenance
86
Front brake fluid reservoir
LWR mark
UPPER level mark
LOWER level mark
Rear brake fluid reservoir
Front Rear
To Next Page
