Honda CLICK125 User Manual

Other Replacement
Replacing the Honda SMART
Key Battery
CA type
If the Honda SMART Key indicator flashes 5
times when the ignition switch is turned to
the (On) position, or the operating range
becomes unstable, replace the battery as
soon as possible.
We recommend to see your dealer for this
service.
Battery type: CR2032
1. Remove the upper case by inserting a
coin or a flat head screwdriver covered
with a protective cloth into the slit.
u Wrap a coin or a screwdriver with a
protective cloth to prevent scratching
the Honda SMART Key.
u Do not touch the circuit or terminal.
This may cause problems.
u Be careful to avoid scratching the
waterproof covering or allowing dust
to enter.
u
Do not forcibly dismantle the Honda
SMART Key body.
20221206110820_32K2VD000_eng_BOOK Page 100 Tuesday, December 06 2022 11:12:16 JST
Maintenance
97
Continued

Honda CLICK125 Specifications

General

Fuel System	PGM-FI (Programmed Fuel Injection)
Starter System	Electric
Front Suspension	Telescopic Fork
Rear Brake	Mechanical Leading Trailing
Front Tire	80/90-14
Rear Tire	90/90-14
Seat Height	769 mm
Curb Weight	111 kg
Bore x Stroke	52.4 x 57.9 mm
Compression Ratio	11.0:1
Ignition System	Full Transistorized
Frame Type	Underbone
Wheelbase	1, 280 mm
Ground Clearance	132 mm
Max Torque	10.8 Nm @ 5, 000 rpm
Engine Type	4-stroke, SOHC
Transmission	V-Matic
Front Brake	Hydraulic Disc
Fuel Tank Capacity	5.5 liters
Max Power	8.3 kW @ 8, 500 rpm
