Honda CLICK125 User Manual

Engine Oil
Checking the Engine Oil
Check the engine oil with the Idling Stop
switch at (Idling).
1. If the engine is cold, idle the engine for 3
to 5 minutes.
2. Turn the ignition switch to the (Off)
position and wait for 2 to 3 minutes.
3.
Place your vehicle on its centre stand on a
firm, level surface.
4. Remove the oil fill cap/dipstick and wipe it
clean.
5.
Insert the oil fill cap/dipstick until it seats,
but don't screw it in.
6. Check that the oil level is between the
upper level and lower level marks on the
oil fill cap/dipstick.
7. Securely install the oil fill cap/dipstick.
20221206110820_32K2VD000_eng_BOOK Page 88 Tuesday, December 06 2022 11:12:16 JST
Maintenance
85
Upper
level
Lower
level
Oil fill cap/dipstick

Honda CLICK125 Specifications

General

Fuel System	PGM-FI (Programmed Fuel Injection)
Starter System	Electric
Front Suspension	Telescopic Fork
Rear Brake	Mechanical Leading Trailing
Front Tire	80/90-14
Rear Tire	90/90-14
Seat Height	769 mm
Curb Weight	111 kg
Bore x Stroke	52.4 x 57.9 mm
Compression Ratio	11.0:1
Ignition System	Full Transistorized
Frame Type	Underbone
Wheelbase	1, 280 mm
Ground Clearance	132 mm
Max Torque	10.8 Nm @ 5, 000 rpm
Engine Type	4-stroke, SOHC
Transmission	V-Matic
Front Brake	Hydraulic Disc
Fuel Tank Capacity	5.5 liters
Max Power	8.3 kW @ 8, 500 rpm
