Honda CLICK125 User Manual

Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 76
#
Fuse Box Fuses
1. Remove the battery lid and the battery
cover from the step floor. 2 P. 83
2.
Pull the fuses out with the fuse puller in
back side of battery cover one by one
check for blown fuse. Always replace a
blown fuse with a spare fuse of the same
rating.
u Spare fuses are provided on back side
of the battery cover.
3. Install the battery lid and the battery
cover.
NOTICE
If a fuse fails repeatedly, you likely have an
electrical problem. Have your vehicle inspected
by your dealer.
20221206110820_32K2VD000_eng_BOOK Page 120 Tuesday, December 06 2022 11:12:16 JST
Electrical Trouble u Blown Fuse
Troubleshooting
117
Continued
Battery cover
Fuse puller
Spare fuses
Main fuse

Honda CLICK125 Specifications

General

Fuel System	PGM-FI (Programmed Fuel Injection)
Starter System	Electric
Front Suspension	Telescopic Fork
Rear Brake	Mechanical Leading Trailing
Front Tire	80/90-14
Rear Tire	90/90-14
Seat Height	769 mm
Curb Weight	111 kg
Bore x Stroke	52.4 x 57.9 mm
Compression Ratio	11.0:1
Ignition System	Full Transistorized
Frame Type	Underbone
Wheelbase	1, 280 mm
Ground Clearance	132 mm
Max Torque	10.8 Nm @ 5, 000 rpm
Engine Type	4-stroke, SOHC
Transmission	V-Matic
Front Brake	Hydraulic Disc
Fuel Tank Capacity	5.5 liters
Max Power	8.3 kW @ 8, 500 rpm
