General| Fuel System | PGM-FI (Programmed Fuel Injection) |
|---|---|
| Starter System | Electric |
| Front Suspension | Telescopic Fork |
| Rear Brake | Mechanical Leading Trailing |
| Front Tire | 80/90-14 |
| Rear Tire | 90/90-14 |
| Seat Height | 769 mm |
| Curb Weight | 111 kg |
| Bore x Stroke | 52.4 x 57.9 mm |
| Compression Ratio | 11.0:1 |
| Ignition System | Full Transistorized |
| Frame Type | Underbone |
| Wheelbase | 1, 280 mm |
| Ground Clearance | 132 mm |
| Max Torque | 10.8 Nm @ 5, 000 rpm |
| Engine Type | 4-stroke, SOHC |
| Transmission | V-Matic |
| Front Brake | Hydraulic Disc |
| Fuel Tank Capacity | 5.5 liters |
| Max Power | 8.3 kW @ 8, 500 rpm |
