Honda CLICK125 User Manual

Engine Does Not Start Even If
the Throttle is Opened
Engine does not start even if the throttle is
opened, perform the followings.
If the side stand is down:
While the engine is stopped by the Idling
Stop system, if you operate the side stand,
the flashing Idling Stop indicator turns off or
stops flashing and stays on, and the Idling
Stop system is cancelled. Restart the engine
with start button referring to the starting
procedure (2 P. 55) for standard engine
starting.
If the Idling Stop switch is at (Idling):
While the engine is stopping by the Idling
Stop system, if you press the Idling Stop
switch to
(Idling), the Idling Stop system
will be cancelled. Restart the engine with start
button referring to the starting procedure
(2 P. 55) for standard engine starting.
If the Idling Stop indicator flashes (the Idling
Stop switch is at
(Idling Stop) position),
but engine does not start even if the throttle
is opened, perform the followings.
Low (or dead) battery or battery lead is loose:
Check the battery and battery terminals. If
the battery is weak, contact your dealer.
20221206110820_32K2VD000_eng_BOOK Page 110 Tuesday, December 06 2022 11:12:16 JST
When the Idling Stop System Does Not Operate Properly u Engine Does Not Start Even If the Throttle is Opened
Troubleshooting
107

Honda CLICK125 Specifications

General

Fuel System	PGM-FI (Programmed Fuel Injection)
Starter System	Electric
Front Suspension	Telescopic Fork
Rear Brake	Mechanical Leading Trailing
Front Tire	80/90-14
Rear Tire	90/90-14
Seat Height	769 mm
Curb Weight	111 kg
Bore x Stroke	52.4 x 57.9 mm
Compression Ratio	11.0:1
Ignition System	Full Transistorized
Frame Type	Underbone
Wheelbase	1, 280 mm
Ground Clearance	132 mm
Max Torque	10.8 Nm @ 5, 000 rpm
Engine Type	4-stroke, SOHC
Transmission	V-Matic
Front Brake	Hydraulic Disc
Fuel Tank Capacity	5.5 liters
Max Power	8.3 kW @ 8, 500 rpm
