Honda CLICK125 User Manual

Coolant
Checking the Coolant
Check the coolant level in the reserve tank
while the engine is cold.
1. Place your vehicle on a firm, level surface.
2. Hold your vehicle in an upright position.
3. Check that the coolant level is between
the UPPER level and LOWER level marks
on the reserve tank.
If the coolant level is dropping noticeably or
the reserve tank is empty, you likely have a
serious leak. Have your vehicle inspected by
your dealer.
Adding Coolant
If the coolant level is below the LOWER level
mark, add the recommended coolant
(2 P. 78) until the level reaches the UPPER
level mark.
Add fluid only from the reserve tank cap and
do not remove the radiator cap.
1. Remove the reserve tank cover by
removing the screw.
2. Remove the reserve tank cap and add
fluid while monitoring the coolant level.
u
Do not overfill above the UPPER level
mark.
u
Make sure no foreign objects enter the
reserve tank opening.
20221206110820_32K2VD000_eng_BOOK Page 90 Tuesday, December 06 2022 11:12:16 JST
Maintenance
87
Continued
UPPER level
mark
LOWER level
mark
Reserve tank cap
Screw
Reserve tank
cover

Honda CLICK125 Specifications

General

Fuel System	PGM-FI (Programmed Fuel Injection)
Starter System	Electric
Front Suspension	Telescopic Fork
Rear Brake	Mechanical Leading Trailing
Front Tire	80/90-14
Rear Tire	90/90-14
Seat Height	769 mm
Curb Weight	111 kg
Bore x Stroke	52.4 x 57.9 mm
Compression Ratio	11.0:1
Ignition System	Full Transistorized
Frame Type	Underbone
Wheelbase	1, 280 mm
Ground Clearance	132 mm
Max Torque	10.8 Nm @ 5, 000 rpm
Engine Type	4-stroke, SOHC
Transmission	V-Matic
Front Brake	Hydraulic Disc
Fuel Tank Capacity	5.5 liters
Max Power	8.3 kW @ 8, 500 rpm
