Honda CRF230F 2017 User Manual

69
CRF230F
Side Stand
(Refer to the Safety Precautions on page 39.)
Check the side stand spring (1) for damage and loss
of tension, and the side stand assembly for freedom
of movement.
If the side stand is squeaky or stiff, clean the pivot
area and lubricate the pivot bolt with clean engine oil.
(1) Side stand spring
(1)
(1) Swingarm
bearings
(2) Attachment points
(2)
(1)
(2)
(1)

Honda CRF230F 2017 Specifications

General

Engine Type	223cc air-cooled single-cylinder four-stroke
Bore and Stroke	65.5mm x 66.2mm
Compression Ratio	9.0:1
Ignition	CDI
Rear Suspension	Pro-Link Showa single shock; 9.0 inches travel
Front Brake	Single 240mm disc
Rear Brake	Drum
Front Tire	80/100-21
Rear Tire	100/100-18
Curb Weight	249 pounds
Final Drive	Chain
Front Suspension	37mm leading-axle Showa fork
Trail	4.4 inches
Induction	Keihin 26mm piston-valve carburetor
