14
CONTROLS & FEATURES
Fuel Valve Lever
The fuel valve lever is located
between the fuel tank and
carburetor.
The fuel valve lever must be in
the ON position for the engine to
run.
After stopping the engine, turn
the fuel valve lever to the OFF
position.
Choke Lever
The choke is used to provide
proper starting mixture when the
engine is cold. It can be opened
and closed by operating the
choke lever manually. Move the
choke lever to the CLOSED
position to enrich the mixture for
cold starting.
FUEL VALVE LEVER
OFF
ON
OPEN
CHOKE LEVER
CLOSED
