56
STORAGE
3. Remove the sediment cup (see page 52), and then turn the fuel
valve lever to the ON position and drain the fuel from the fuel tank.
4. After all the fuel has drained into the container, tighten the
carburetor drain bolt securely.
5. Install the sediment cup and a new O-ring.
6. Turn the fuel valve lever to the OFF position.
Engine Oil
Change the engine oil (see page 44).
Engine Cylinder
1. Remove the spark plug, and pour a teaspoon (5 cc) of clean engine
oil into the cylinder. Crank the engine several revolutions to
distribute the oil, then reinstall the spark plug.
2. Slowly pull the starter grip until resistance is felt. At this point, the
piston is coming up on its compression stroke, and both the intake
and exhaust valves are closed. Storing the engine in this position
will help to protect it from internal corrosion.
Align the notch on the starter pulley
with the hole at the top of recoil starter.
31Z306120.book 56 ページ ２０１５年１１月２７日 金曜日 午前１０時２５分
