ASSEMBLY
ASSEMBLY
HANDLE INSTALLATION (Optional Parts)
Install the right and left handles on the generator upper frame using
the handle brackets and four flange bolts.
TORQUE: 17–22 lbf·ft (24–29 N·m, 2.4–3.0 kgf·m)
8×16 mm FLANGE BOLT (4)
LEFT HANDLE BRACKET
RIGHT UPPER HANDLE ASSY
RIGHT HANDLE
BRACKET
LEFT UPPER HANDLE ASSY
