86
INITIAL USE INSTRUCTIONS
ENGINE OIL
The generator is shipped WITHOUT OIL in the engine.
1. Place the generator on a level surface.
2. Remove the oil filler cap.
3. Add enough oil to bring the oil level to the upper limit of the oil filler
neck. SAE 10W-30 API service category SJ or later (or equivalent) is
recommended for general use; for additional recommendations
(see page 45).
Maximum oil capacity: 1.2 US qt (1.1 L)
Do not overfill the engine with oil. If the engine is overfilled, the
excess oil may be transferred to the air cleaner housing and air filter.
4. Reinstall the oil filler cap securely.
OIL FILLER CAP
UPPER LIMIT
OIL FILLER NECK
