52
SERVICING YOUR GENERATOR
SEDIMENT CUP CLEANING
The sediment cup prevents dirt or water that may be in the fuel tank
from entering the carburetor. If the engine has not been run for a long
time, the sediment cup should be cleaned.
1. Turn the engine switch to the OFF position.
2. Turn the fuel valve lever to the
OFF position; then remove the
sediment cup and the O-ring.
Discard the O-ring.
3. Clean the sediment cup in
nonflammable solvent, and dry
it thoroughly.
4. Reinstall a new O-ring and
sediment cup, and tighten the
sediment cup securely.
5. Turn the fuel valve lever to the
ON position and check for leaks.
Gasoline is highly flammable and
explosive.
You can be burned or seriously
injured when handling fuel.
• Stop the engine and keep heat,
sparks, and flame away.
• Handle fuel only outdoors.
• Wipe up spills immediately.
FUEL VALVE LEVER
O-RING
(Replace)
SEDIMENT CUP
OFF
