Honda EU22i User Manual

12
CONTROLS & FEATURES
CONTROLS
Engine Switch
The engine switch controls the
ignition system and the fuel
valve.
OFF – Stops the engine and
closes the fuel valve.
FUEL OFF – Keeps the ignition
system ON, and closes only the
fuel valve. (see page 26)
ON – Running position; opens the
fuel valve and allows the engine
to be started.
Starter Grip
Pulling the starter grip operates
the recoil starter to start the
engine.
Do not allow the starter grip to
snap back against the generator.
Return it gently to prevent
damage to the starter.
ENGINE
SWITCH
ON
OFF
STARTER
GRIP
FUEL OFF
32Z446000.book Page 12 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
