Honda EU22i User Manual

17
CONTROLS & FEATURES
Output Indicator
The output indicator (green) is illuminated when the generator is
operating normally. It indicates that the generator is producing
electrical power at the receptacles.
In addition, the output indicator has a simplified hour meter function.
When you start the engine, the indicator blinks according to the
generator’s cumulative operating hours as follows:
• No blinks: 0–100 hours
• 1 blink: 100–200 hours
• 2 blinks: 200–300 hours
• 3 blinks: 300–400 hours
• 4 blinks: 400–500 hours
• 5 blinks: 500 or more hours
OUTPUT INDICATOR
(GREEN)
32Z446000.book Page 17 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
