Honda EU22i User Manual

14
CONTROLS & FEATURES
Eco Throttle Switch
The Eco Throttle system automatically reduces engine speed when
loads are turned off or disconnected. When appliances are turned on or
reconnected, the engine returns to the proper speed to power the
electrical load.
If high electrical loads are connected simultaneously, turn the
Eco Throttle switch to the OFF position to reduce voltage changes.
When using the DC output, turn the Eco Throttle switch to the OFF
position.
ON: Recommended to minimize fuel consumption and further reduce
noise levels when less than a full load is applied to the generator.
OFF: The Eco Throttle system does not operate.
Parallel Operation Outlets
These outlets are used for connecting both types of the EU22i
generator or EU20i generator for parallel operation (see page 31
through 36). A Honda approved receptacle box (optional equipment) is
required for parallel operation. This receptacle box can be purchased
from an authorized Honda generator dealer.
ECO THROTTLE SWITCH
OFF
ON
PARALLEL OPERATION OUTLETS
32Z446000.book Page 14 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
