Honda EU22i User Manual

67
TECHNICAL INFORMATION
Specifications
Dimensions
Engine
Generator
Tune-up Specifications
Specifications are subject to change without notice.
Model EU22iT
Description code EAMT
Length 509 mm
Width 290 mm
Height 425 mm
Dry mass [weight] 21.1 kg
Model GXR120T
Engine type 4-stroke, overhead camshaft, single cylinder
Displacement
[Bore × Stroke]
121 cm
3
[60.0 × 43.0 mm]
Compression ratio 8.5:1
Engine speed 4,000 – 4,500 rpm
(with Eco Throttle switch OFF)
Cooling system Forced air
Ignition system Full transistor
Engine oil capacity 0.44 L
Fuel tank capacity 3.6 L
Spark plug CR5HSB (NGK)
Model EU22iT
Type U4
AC output
Rated voltage (V) 240
Rated frequency (Hz) 50
Rated current (A) 7.5
Rated output (kVA) 1.8
Maximum output (kVA) 2.2
DC output
Only for charging 12 V automotive batteries.
Maximum charging output = 8.3 A
ITEM SPECIFICATION MAINTENANCE
Spark plug gap
0.6 – 0.7 mm Refer to page 54.
Valve clearance
(cold)
IN: 0.15 ± 0.04 mm
EX: 0.20 ± 0.04 mm
See your authorized
Honda dealer.
Other specifications No other adjustments needed.
32Z446000.book Page 67 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
