Honda EU22i User Manual

48
SERVICING YOUR GENERATOR
ENGINE OIL LEVEL CHECK
Check the engine oil level with the generator on a level surface and
the engine stopped.
1. Loosen the maintenance cover screw and remove the maintenance
cover.
2. Remove the oil filler cap and wipe the dipstick clean.
3. Check the oil level by inserting the dipstick into the oil filler neck
without screwing it in.
4. If the level is low, fill to the upper limit of the oil filler neck with the
recommended oil (see page 50).
5. Reinstall the oil filler cap securely.
6. Reinstall the maintenance cover and tighten the maintenance cover
screw securely.
The Oil Alert system will automatically stop the engine before the oil
level falls below safe limits. However, to avoid the inconvenience of an
unexpected shutdown, check the oil level regularly.
MAINTENANCE COVER SCREW
MAINTENANCE
COVER
OIL FILLER NECK
UPPER LIMIT
OIL FILLER CAP
LOWER LIMIT
32Z446000.book Page 48 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
