19
CONTROLS & FEATURES
LED Light Patterns
: ON
: OFF
: Blinking
Refer to
TAKING CARE OF UNEXPECTED PROBLEMS
on page 64 for
failure diagnosis.
Status Possible cause Output Indicator Overload indicator Oil Alert Indicator
Normal Operating
normally
Malfunction Inverter unit
failure
Abnormal Output
overcurrent
Inverter unit
overheat
Warning Engine oil low
OIL ALERT INDICATOR
OVERLOAD INDICATOR
OUTPUT INDICATOR
32Z446000.book Page 19 Friday, February 2, 2018 3:46 PM
