Honda EU22i User Manual

51
SERVICING YOUR GENERATOR
AIR CLEANER SERVICE
1. Loosen the maintenance
cover screw and remove the
maintenance cover.
2. Loosen the air cleaner cover
screw, and remove the air
cleaner cover.
3. Remove the main and outer
filters from the air cleaner housing.
4. Check the main and outer filters to be sure they are clean and in
good condition. If the main and outer filters are dirty, clean them as
described on page 53. Replace the main and outer filters if they are
damaged.
MAIN FILTER
MAINTENANCE COVER
SCREW
MAINTENANCE COVER
AIR CLEANER
COVER SCREW
OUTER FILTER
AIR CLEANER COVER
32Z446000.book Page 51 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
