Honda EU22i User Manual

53
SERVICING YOUR GENERATOR
MAIN AND OUTER FILTER CLEANING
Dirty air filters will restrict air flow to the carburetor, reducing engine
performance. If you operate the generator in very dusty areas, clean
the main and outer filters more frequently than specified in the
Maintenance Schedule.
1. Clean the air filters in warm soapy water, rinse, and allow to dry
thoroughly, or clean in nonflammable solvent and allow to dry.
2. Dip the air cleaner element in clean engine oil, and then squeeze out
all excess oil. The engine will smoke when started if too much oil is
left in the air filters.
3. Wipe dirt from the air cleaner housing and cover using a moist rag.
Be careful to prevent dirt from entering the air duct that leads to the
carburetor.
Clean
Squeeze and dry
Dip in oil
Squeeze
Do not twist. Do not twist.
32Z446000.book Page 53 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
