TECHNICAL SPECIFICATIONS
(*) The power rating of the engine indicated in this document is the net power output tested on a production engine for the engine model GXV160H2 and
measured in accordance with SAE J1349 at 3 600 min
-1
(Net Power). Mass production engines may vary from this value. Actual power output for the
engine installed in the final machine will vary depending on numerous factors, including the operating speed of the engine in application, environmental
conditions, maintenance, and other variables.
(**) The CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type
(engine family) and shall not imply or express any guarantee of the performance of a particular engine.
MODELS
HRD536K4 HRH536K4
QXEH HXEH HXEH QXEH
GENERAL CHARACTERISTICS
Description code MZBL MZBU
Function Cutting of grass
Dimensions L x W x h mm 1 655 x 574 x 1 031 1 575 x 574 x 1 018 1 695 x 575 x 1 020
Dry weight (without oil, fuel) kg 53.5 49.3 60.2 58.1
Track FR/RR mm 476/490 476/512 484/518 484/490
Cutting width cm 53
Cutting heights settings mm 5 (14-52) 7 (14-76) 6 (21-76)
5 (14-52)
Front/Rear wheel diameter mm 200/100 200/200 225/225 225/101.6
Grass catcher capacity
83 80 83
Sound pressure level at operator’s ears
(in accordance with EN ISO5395-2:2013 +
A1:2016 + A2:2017) dB(A)
83.50 82.40
Measuring uncertainty (EN 12096) dB(A) 1.00
Sound power level measured (in accordance
with directives 2000/14/EC, 2005/88/EC)
95.83 96.11
Measuring uncertainty dB(A) 0.53 0.70
Sound power level guaranteed (in accordance
with directives 2000/14/EC, 2005/88/EC) dB(A)
98
Vibration test (in accordance with
EN ISO5395-2:2013 + A1:2016 + A2:2017) m/s
2
2.65 4.26
Measuring uncertainty (EN 12096) m/s
2
1.33 2.13
ENGINE
Model GXV160H2
Type Air-cooled overhead valve 4-stroke engine
Displace
ment cc
163
Bore x Stroke 68.0 x 45.0
Cooling Forced air
Lubrication Spray lubrication
Compression ratio 8.0 : 1
Net power (*) kW/min
-1
3.2 / 3 600
Nominal power kW/min
-1
2.7 / 2 800
Operating speed min
-1
2 800
Idle speed min
-1
1 700 ± 150
Ignition Transistorised magneto ignition
Spark plug BPR5ES (NGK), W16 EPR-U (NIPPONDENSO Co., Ltd.)
Electrode gap mm 0.7 to 0.8
Air cleaner Dual type
Recommended fuel Unleaded
Fuel tank capacity
1.5
Fuel consumption
/h
0.65
Recommended oil SAE 10W30
Engine oil capacity
0.65
Carbon dioxide (CO2) emissions(**)
Please refer to "CO2 Information List" on
www.honda-engines-eu.com/co2
TRANSMISSION
Type Gear/chain 1 speed Hydrostatic Gear/chain 1 speed
Engine to drive Shaft V-belt Shaft
Final transmission Chain Direct Chain
Main clutch Dog clutch Neutral valve (open/close) Dog clutch
Number of speeds 1 Variation 1
Forward speed m/s 1.2 0-1.4
0.8-1.4
1.2
Lubrication Oil bath and splash Oil bath Oil bath and splash
Recommended oil SAE90
Honda HST oil
or Honda Ultra U
Honda HST oil SAE90
Oil capacity cc 160 140 340 160
