1/8 5/16 in
(3 8 mm)
1/85/16in(38mm)
(1)
(2)
(B)
((AA))
RIGHT HANDLEBAR
(1) throttle lever
(2) rubber sleeve
(3) throttle cable adjuster
(4) lock nut
(A) decrease freeplay
(B) increase freeplay
(3) (4)
133
Throttle Freeplay
Throttle
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Check freeplay at the throttle lever ( ).
Freeplay:
Inspection
After adjustment, check for smooth operation of the throttle lever
from fully closed to fully open in all steering positions.
Tighten the lock nut and reinstall the sleeve.
Loosen the lock nut ( ).
Turn the adjuster to obtain the correct freeplay.
Slide the rubber sleeve ( ) back to expose the throttle cable adjuster
().
Adjustment
1
1.
2.
3.
4.
5.
2
4
3
99
