TRX500FPE
(2)
(1)
(7) multi-function display
(8) hour select button
(9) minute select button
(10) adjust button
(11) PS (Electric Power
Steering) indicator
(TRX500FPE only)
(1) RESET button
(2) odometer/tripmeter
select button
(3) 4WD indicator
(4) high oil temperature indicator
(5) neutral indicator
(6) reverse indicator
14
Indicators & Displays
Instruments & Controls
The indicators and displays on your ATV keep you informed, alert you
to possible problems, and make your riding safer and more enjoyable.
Refer to the indicators frequently. Their functions are described on the
following pages.
USA: Displays read in mph and miles.
Canada: Displays read in km/h and kilometers.
