3.96 US gal (15.0 )
0.66 US gal (2.5
)
0.66 US gal (2.5
)
(1)
(2)
(1) fuel gauge
(2) segment RES
(3) segment E
(4) low fuel indicator
(1)
(4)
(3)
TRX500FPETRX500FE
TRX500FE TRX500FPE
26
Fuel Gauge
Indicators & Displays
Instruments & Controls
The fuel gauge liquid crystal display ( ) shows the approximate fuel
supply available. The fuel tank capacity is:
When segment E ( ) and low fuel indicator ( ) flash, you should refill
the tank as soon as possible. The amount of fuel remaining when the
flashing starts is approximately:
When segment RES ( ) flashes, you should refill the tank as soon as
possible. The amount of fuel remaining when the flashing starts is
approximately:
All segments will flash, when the fuel gauge function is fails. See your
Honda dealer.
1
TRX500FPE:
4
TRX500FE:
2
3
