(1)
(2)
(3)
(1) oil change indicator
(2) odometer/tripmeter
select button
(3) RESET button
TRX500FE TRX500FPE
(1)
(3)
(2)
20
Oil Change Indicator
Instruments & Controls
Indicators & Displays
The oil change indicator ( ) appears in the display when the mileage or
operating hours on your ATV approaches the oil change interval
specified on the maintenance schedule.
If the oil is changed before the oil change indicator appears, be sure to
reset the oil change indicator after changing the oil. The indicator will
appears for 2 seconds, then disappear. This means the indicator is reset.
Reset the indicator after each oil change.
To reset the indicator, press and hold both the odometer/tripmeter select
button ( ) and RESET button ( ) for more than 2 seconds. The
indicator will disappear.
2
1
3
１０／０２／１２ １４：５４：４７ ３１ＨＰ０９７０ ００２９
