(2)
(3) utility box cover(1) utility box
(2) D-ring
(3)
(1)
LEFT FRONT FENDER
43
Utility Box
Controls & Features
Instruments & Controls
To open:
To close:
The utility box ( ) is located on the left side of the front fender. You
may store small, lightweight items in the box.
Lift the D-ring ( ) on the quick-release fastener. Turn it
counterclockwise until it releases. Open the utility box cover ( ).
Close the cover and turn the D-ring clockwise until it secures the cover.
1
2
3
１０／０２／１２ １４：５７：２５ ３１ＨＰ０９７０ ００５２
