2 - 15
RS-232 Baud Rate
Baud Rate sends the data from the image scanner to the terminal at the speci-
fied rate. The host terminal must be set for the same baud rate as the image
scanner.
Default = 115,200.
RS-232 Word Length: Data Bits, Stop Bits, and Parity
Data Bits sets the word length at 7 or 8 bits of data per character. If an applica-
tion requires only ASCII Hex characters 0 through 7F decimal (text, digits, and
punctuation), select 7 data bits. For applications which require use of the full
ASCII set, select 8 data bits per character.
Default = 8.
Stop Bits sets the stop bits at 1 or 2.
Default = 1.
300
2400
600
1200
4800
38400
9600
19200
* 115,200
57,600
To Next Page
