26
Mounting and Connection Instructions Reader series "luminAXS"
1.3 Interfaces
RS-485: Bidirectional interface with "Modulbus" protocol,
Interface range up to 2000 m
Clock/Data: Unidirectional interface, TTL-level, 4 bit code according to DIN 9785, active = LOW
Interface range up to 200 m
Only the same interfaces can be used in one system (RS-485 or Clock/Data).
1.2 Performance features
- Clear and logical operating concept.
- Simple start-up.
- Simple RS-485 address allocation, manual or automatic.
- Automatic adjustment of transmission range.
- By use of MIFARE DESFire EV1/EV2 readers extreme safety is available (see 2.2).
- Synchronization of max. 3 readers installed close to one another.
- Lighting ring. Colour, brightness and function programmable.
- The reader is completely protected against humidity.
-.For use outdoors and indoors (-25 °C to +65 °C)
- Simple assembly, surfaces of metal is possible.
- The reader can be directly mounted on commercially available f.m. sockets (DIN).
Special keypad features:
- Neutral labelling of LEDs and keypad.
- Abrasion-resistant 10 key keypad with 6 additional functional keys.
-Ta .ctile and acoustical acknowledgement
- Night design with time-limited luminous background.
1.4 System conditions
*) only required for MIFARE DESFire EV1/EV2
RS-485 Clock/Data
IK3EU BUS-2 from V12.xx *) ACS-8 from V09.xx *) X
IK3 EU conv. ACS-2 plus X
Door contr. mod. BUS-2 from V12.xx *) ACT X
MB panels from V14.xx *) Door controller RS-485 X
MB-Secure from V05.xx *) AXS4Secure from V05.xx *)
Foreign devices
Software
WINFEM Advanced from V14.xx *) IQ MultiAccess from V12.xx *)
IQ PanelControl from V05.xx *)
IQ SystemControl from V07.xx *)
Software
ACS
Interface
Device Device
For installation in accordance with VdS / EN / SES regulations
interface RS-485 must be used.
For installation in accordance with VdS / EN / SES regulations
interface RS-485 must be used.
