Honeywell MS3780 Fusion User Manual

27
DESIGN SPECIFICATIONS
MS3780
Operational
Normal Depth of Field: 25 mm - 280 mm (1"- 11")
0.33 mm (13 mil)
bar code
Reduced Depth of Field: 25 mm - 150 mm (1"- 6")
Omni Scan
Scan Speed: 1333 scan lines per second
No. of Scan Lines: 20
Single-Line
Scan Speed: 67 scan lines per second
No. of Scan Lines: 1
Motor Speed: 4000 RPM
Min Bar Width: 0.127 mm (5.0 mil)
Decode Capability:
All standard 1-D bar codes including RSS-14,
RSS-Expanded, and RSS-14 Limited
System Interfaces:
RS232, Keyboard Wedge, Stand-Alone Keyboard, Light Pen
Emulation, RS485, USB (low speed and full speed), OCIA
Print Contrast: 35% minimum reflectance difference
No. Characters Read:
Up to 80 data characters
Maximum number will vary based on symbology and density.
Beeper Operation: 7 tones or no beep
Indicators (LED):
Blue = laser on, ready to scan
White = good read, decoding
Termination: 10 position modular RJ45 connector
Cable: Application Dependent
Embedded Laser
Max Optical Power: 10 mW
Wavelength: 640 – 660 nm
Min Bean Divergence: 6°
Mechanical
Scanner Length: 189 mm (7.44")
Scanner Width: 65 mm (2.56")
Scanner Height: 73 mm (2.88")
Scanner Weight: 195 g (6.9 oz.)
Specifications subject to change without notice.

Honeywell MS3780 Fusion Specifications

General

Scan speed	1333 sec/page
Wavelength	650 nm
Decoding standards	1D, GS1
Dimensions (WxDxH)	189 x 65 x 73 mm
Standard interfaces	Keyboard wedge
Input voltage	5 V
Certification	FCC Part 15, ICES-003, EN55022 Class B
Product color	Black
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-20 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	195 g
