Honeywell MS3780 Fusion User Manual

1
INTRODUCTION
The MS3780 Fusion
®
is a hand-held, omnidirectional bar code scanner with
optional single-line scanning capabilities. It utilizes the powerful Honyewell
QuantumE
®
scan engine to provide an outstanding scan performance on all
standard 1D bar code symbologies, including GS1 DataBar™ (RSS). Designed
for retail applications, the Fusion includes additional key product features like:
• Fully Automatic Scanning Operation
• Single-Line Mode for Menu Reading
• Custom Configurable Scan Pattern
• User-Replaceable Single-Cable Interface to Host (PowerLink Compatible)
• User Configurable Depth of Field
• Easy Bar Code Configuration
• Data Editing
• 7 Beeper Tones
• Firmware updates are easily loaded into Flash memory
• OPOS and JPOS System Compatible
• CodeGate
®
• Sunrise 2005 Compliant
SCANNER INTERFACE
MS3780-9 OCIA and RS232 Transmit/Receive
MS3780-11 RS485

and Full RS232
MS3780-38
RS232 Low Speed USB*,
Keyboard Emulation Mode or USB Serial Emulation Mode
MS3780-40 Full Speed USB
MS3780-41 RS232/Light Pen Emulation
MS3780-47
Keyboard Wedge, Stand-Alone Keyboard and
RS232 Transmit/Receive
MS3780-48 Stand Alone Keyboard and RS232 Transmit/Receive
MS3780-120 USB and RS232 Transmit/Receive with EAS
* Configurable for Keyboard Emulation Mode or Serial Emulation Mode.
The default setting is Keyboard Emulation Mode.

Applicable for IBM
®
Host applications.

Honeywell MS3780 Fusion Specifications

General

Scan speed	1333 sec/page
Wavelength	650 nm
Decoding standards	1D, GS1
Dimensions (WxDxH)	189 x 65 x 73 mm
Standard interfaces	Keyboard wedge
Input voltage	5 V
Certification	FCC Part 15, ICES-003, EN55022 Class B
Product color	Black
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-20 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	195 g
