ID2000 Series Operating Manual
Operator Actions at Panel
14997-434-000-4, Issue 4
May 2010
4.8 System Test
To perform a system test press the ‘0’ pushbutton when
the Top Level display is present. The TEST menu is
displayed:
These options allow you to:
a. Perform a ZONE WALK TEST.
b. Perform an individual CONTROL OUTPUT TEST.
c. Perform a LAMP TEST (see Section 4.7).
Additional options may be available, depending upon the
configuration of the panel. The option numbers vary,
depending upon how many options are available:
d. Perform a SENSOR AUTOMATIC TEST.
e. Perform a REPLACE VIEW SENSOR operation.
Example TEST menus are shown below:
TEST: 0=Zone/1=Output/2=Lamps:
TEST: 0=Zone/1=Output/2=Lamps:
3=Replace Sensor:
TEST: 0=Zone/1=Output/2=Lamps:
3=(Daily)(Weekly) automatic test NOW/
4=Replace Sensor:
