PX4ie and PX6ie High Performance Printer User Guide 9
Set the Command Language from the Printer Webpage
To set the command language from the printer webpage, you need to turn on the
printer and connect to your Ethernet network.
1. Make sure that the printer has media and ribbon (if necessary) installed.
2. On your PC, open a Web browser.
3. In the Location or Address bar, type the printer IP address and press Enter. The
printer webpage appears.
4. Click Login.
5. Type your Username and Password and click Login. the default username is
itadmin and the default password is pass.
6. Click the Configure tab.
7. Click System Settings > General.
8. Select a different printer command language from the Command Language
list, and then click Save.
9. Click the Services tab.
10. Click Reboot Printer, and then click Reboot. The printer restarts in the
command language you selected.
Printer Options and Accessories
Options are either installed at the factory or by factory service technicians in the
field. Accessories are designed to be installed by the customer. Options and acces-
sories are sold separately.
Option/Accessory Description
Liner/Batch Takeup This factory-installed option separates labels
from the liner and windsup the spent liner inside
the printer’s media compartment.
Paper Cutter Use the paper cutter to cut through continuous
non-adhesive paper-based media or the liner
between labels.
If you are running Fingerprint or Direct Protocol,
you can control the paper cutter using the
commands CUT, CUT ON, and CUT OFF.
Media Roll Retainer Use the media roll retainer with a rotating media
supply hub to keep large media rolls in place.
76 mm (3-in)
Adapter
Use the 76 mm (3-in) adapter with a rotating
media supply hub to use media rolls with 76 mm
(3-in) inner diameter cores.
The adapter cannot be used with a media supply
roll post.
