4-71
Remote Operation
DISPlay Subsystem Commands
DISPlay Subsystem Commands
DISPlay[:WINDow[1]]:ANNotation[:ALL] ON|OFF|0|1
DISPlay[:WINDow[1]]:ANNotation[:ALL]?
Turns the screen annotation
ON
or
OFF
. Affects only the X-axis and Y-axis
labeling and labeling within the graticule.
DISPlay[:WINDow[1]]:TEXT:CLEar
Erases all text on the display resulting from previous use of the DISPlay[:WIN-
Dow[1]]:TEXT:DATA command.
DISPlay[:WINDow[1]]:TEXT:DATA <string>|<data_block>
DISPlay[:WINDow[1]]:TEXT:DATA?
Writes text on the display in the Title area. Use the <data_block> parameter to
send extended ASCII characters such as control codes and symbols.
DISPlay[:WINDow[1]]:TRACe:ALL[:SCALe][:AUTO]
Finds the largest input signal using trace A and sets the span and vertical scale
to display that signal. This command performs the same function as the front-
panel
Auto-Meas
key.
The following defines the instrument state settings altered by Auto Measure.
State settings that are not listed are not altered.
Because many instrument state setting are altered, it is recommended you use
this command only to find unknown signals. It is not recommend this com-
mand be used in the middle of a measurement routine.
Center Wavelength According to signal wavelength and bandwidth
Span Set according to automeasure setup panel. In some cases, this
may also be a function of signal characteristics.
Grating Order Auto
book.book Page 71 Monday, January 31, 2000 10:34 AM
